參數規格
| 公稱尺寸Φd1/d2 | ΦD1/D2 | L/l | H1/H2 |
|---|---|---|---|
| Φ25/20 | 32/27 | 19/16 | 65/32 |
| Φ32/20 | 40/27 | 22/16 | 70/34 |
| Φ32/25 | 40/32 | 22/19 | 76/39 |
| Φ40/20 | 49/27 | 26/16 | 79/40 |
| Φ40/25 | 49/32 | 26/19 | 82/42 |
| Φ40/32 | 49/40 | 26/22 | 92/46 |
| Φ50/20 | 60/27 | 31/16 | 89/46 |
| Φ50/25 | 60/32 | 31/19 | 94/49 |
| Φ50/32 | 60/40 | 31/22 | 99/50 |
| Φ50/40 | 60/49 | 31/26 | 111/56 |
| Φ63/25 | 75/32 | 38/19 | 108/56 |
| Φ63/32 | 73/40 | 38/22 | 115/58 |
| Φ63/40 | 73/49 | 38/26 | 120/60 |
| Φ63/50 | 75/60 | 38/31 | 135/68 |
| Φ75/32 | 87/40 | 44/22 | 126/65 |
| Φ75/50 | 87/60 | 44/31 | 142/70 |
| Φ90/32 | 104/40 | 51/22 | 140/73 |
| Φ90/50 | 104/60 | 51/31 | 155/78 |
| Φ90/63 | 104/73 | 51/38 | 170/85 |
| Φ110/32 | 126/40 | 61/22 | 160/85 |
| Φ110/63 | 126/73 | 61/38 | 190/95 |
| Φ110/75 | 126/87 | 61/44 | 212/102 |
| Φ140/50 | 160/61 | 76/31 | 214/106 |
| Φ140/63 | 160/73 | 76/38 | 237/118 |
| Φ140/75 | 160/87 | 76/44 | 237/120 |
| Φ140/110 | 160/126 | 76/61 | 272/140 |
| Φ160/63 | 181/75 | 76/38 | 225/122 |
| Φ160/110 | 181/124 | 86/61 | 293/145 |
| Φ200/110 | 222/124 | 106/61 | 330/164 |
| Φ200/160 | 228/184 | 104/86 | 420/193 |
| Φ225/110 | 250/124 | 100/61 | 310/179 |
| Φ225/160 | 252/184 | 119/86 | 416/205 |
| Φ250/160 | 280/184 | 130/86 | 520/219 |
| Φ280/160 | 312/184 | 148/86 | 541/230 |
| Φ280/225 | 312/252 | 146/119 | 541/264 |
| Φ315/160 | 352/184 | 163/86 | 570/250 |
| Φ315/225 | 352/252 | 163/119 | 570/285 |
| Φ355/225 | 395/265 | 180/119 | 730/300 |
| Φ400/315 | 440/352 | 206/163 | 748/380 |
